TECHNICAL DATA
Dimensions
span: 9.72 m (31.89 ft)
length: 11.49 m (37.70 ft)
height: 4.76 m (15,62 ft)
wing area: 23.52 sqm (253.20 sqft)
Weights
empty: 4,610 kg (10.165 lb)
takeoff (clean): 6,700 kg (14.770 lb)
takeoff (maximum): 9,500 kg (20.945 lb)
empty: 4,610 kg (10.165 lb)
takeoff (clean): 6,700 kg (14.770 lb)
takeoff (maximum): 9,500 kg (20.945 lb)
Power Plant
Honeywell: 2 x F-124GA-200
Thrust, max, SLS, ISA: 2 x 2,850 kg (2 x 6.280 lb)
Internal fuel (usable): 2,000 kg (4.410 lb)
Honeywell: 2 x F-124GA-200
Thrust, max, SLS, ISA: 2 x 2,850 kg (2 x 6.280 lb)
Internal fuel (usable): 2,000 kg (4.410 lb)
Performance (clean, ISA)
Max level speed (sea level): 590 KTAS
Limit speed: 572 KEAS / 1.2 MN
Stall speed (landing, 20% fuel): 90 KCAS
Rate of climb (SL): 21,000 ft/min
Service ceiling: 45,000 ft
Range / 3 ext. tanks (10% reserve): 1,120 / 1,540 nm
Max sustained Load Factor (S.L.): 8.0 g
Max sustained Load Factor (15,000 ft): 5,8 g
Max sustained Turn Rate (15,000 ft): 14 deg/sec
Takeoff ground run (S.L.): 320 m (1.050 ft)
Landing ground roll (S.L., 20% internal fuel): 470 m (1.540 ft)
Limit Load factor: + 8 / -3 g
